J5Create USB 3.0 to LAN Gigabit Ethernet Converter (JUE130)

Product Description • Quickly add a Gigabit Ethernet port through USB™ 3.0 • USB™ 3.0 plug-and-play and backwards compatible with USB™ 2.0/1.1 • Transfer all your files almost instantly over a true Gigabit network • IEEE 802.3, 802.3u and 802.3ab (1BASE-T, 100BASE-TX, and 1000BASE-T) compatible • USB™ bus-powered • Compatible with Windows® and macOS® • Activity and Link LED indicators The JUE130 USB™ 3.0 Gigabit Ethernet Adapter is a simple, one-piece external adapter that plugs into the USB™ port on your Ultrabook™ or MacBook®. It is the ultimate solution if you do not have an Ethernet port or if you just want to increase your connection speed. The elegantly designed JUE130 uses an RJ-45 connector that supports 10/100/1000 Mbps Ethernet performance and allows you to add networking capabilities to a computer without them through a Wireless LAN connection. Interface USB™ Port USB™ 3.0 A-Type Male connector supporting USB™ 3.0 & 2.0 & 1.1 specifications Ethernet Port RJ-45 Female connector Transfer Rate Maximum Data 1000 Mbps (Half Duplex) / 1000 Mbps (Full Duplex) Power Power Mode Bus-Powered Supports IEEE IEEE 802.3az, IEEE 802.3, 802.3u, and 802.3ab, IEEE 802.3x Modes Supports Wake on LAN function, suspend mode and remote wakeup via link-change, Magic Packet™, or Microsoft® wake-up frame Supports IEEE 802.1Q VLAN tagging and 2 VLAN ID filtering Supports Jumbo Frame Supports Checksum Offload (IPv4, IPv6, TCP, UDP) and TCP Large Send Offload Physical Specifications LED Indicators Network Link / Activity Housing Material Aluminum Dimensions Main Body 83 (W) x 57 (H) x 16 (D) mm USB™ Cable Length 5.71 in (0.145 m) Weight 0.09 lbs (0.04 kg) System Requirements Windows® 10 / 8.1 / 8 / 7 / Windows Vista™ / XP macOS® X 10.6 or later Linux® Kernel 3.x / 2.6.x Nintendo Switch compatible Available USB™ port (USB™ 3.0 is recommended) Driver not required for Linux® 3.x / Chrome OS™ 3.8 Driver will automatically install on Windows® 7 / 8.1 / 10 (Requires internet access) NOTE: A manual installation may still be required on Windows® 7 / 8.1 / 10 Package Contents 1 x JUE130 USB™ 3.0 Gigabit Ethernet Adapter 1 x Driver CD 1 x Quick Installation Guide
