Intel® Core™ Ultra 5 225 / 225F (10-Core/10-Threads) Intel Processor | Intel Ultra Series 2 (LGA1851)

Product Highlights • 10-core hybrid architecture with 6 Performance-cores and 4 Efficient-cores • Maximum turbo frequency of up to 4.90GHz • Integrated Intel AI Boost NPU accelerates supported AI workloads • Supports up to 256GB of high-speed DDR5-6400 memory • PCIe 5.0 and PCIe 4.0 support provides high-speed expansion connectivity • 65W processor base power with up to 121W maximum turbo power • Core Ultra 5 225 includes integrated Intel Graphics • Core Ultra 5 225F requires a dedicated graphics card • Boxed 225 and 225F processors include an Intel Laminar RM2 cooler Key Specifications Product Type: Desktop Processor Available Models: Intel Core Ultra 5 225 and Intel Core Ultra 5 225F Product Series: Intel Core Ultra Processors Series 2 Code Name: Arrow Lake CPU Socket: LGA1851 Total Cores: 10 Performance-Cores: 6 Efficient-Cores: 4 Total Threads: 10 Maximum Turbo Frequency: 4.90GHz Performance-Core Maximum Turbo Frequency: 4.90GHz Efficient-Core Maximum Turbo Frequency: 4.40GHz Performance-Core Base Frequency: 3.30GHz Efficient-Core Base Frequency: 2.70GHz Intel Smart Cache: 20MB Total L2 Cache: 22MB Processor Base Power: 65W Maximum Turbo Power: 121W CPU Lithography: TSMC N3B Maximum Operating Temperature: 105°C Memory Type: DDR5 Maximum Memory Speed: DDR5-6400MT/s Maximum Memory Capacity: 256GB Memory Channels: 2 PCI Express Version: PCIe 5.0 and PCIe 4.0 Maximum PCI Express Lanes: 24 Integrated NPU: Intel AI Boost NPU Performance: Up to 13 TOPS Cooler: Intel Laminar RM2 Core Ultra 5 225: Model Code: BX80768225 Integrated Graphics: Intel Graphics Graphics Cores: 2 Xe-Cores Maximum Graphics Frequency: 1.80GHz Overall AI Performance: Up to 23 TOPS Core Ultra 5 225F: Model Code: BX80768225F Integrated Graphics: No Dedicated Graphics Requirement: Yes Overall AI Performance: Up to 19 TOPS Size & Weight Dimensions: 45 x 37.5 mm Weight: 30 g What’s in the Box • Intel Core Ultra 5 225 or 225F Processor • Intel Laminar RM2 Cooler • Installation Documentation Warranty: 3 Year Warranty
