DEEPCOOL GAMERSTORM PFX PF500X PF600X PF700X 80Plus Bronze ATX Power Supply

Product Highlights • Available in 500W, 600W, and 700W options for different desktop PC builds • 80PLUS 230 EU Bronze certified with ≥88% efficiency under typical 50% load • Active PFC + DC-to-DC topology provides stable and efficient power delivery • 120mm Longlife HYB fan helps deliver reliable cooling performance • Built with Taiwanese + Japanese electrolytic capacitors for improved durability • Full protection design with OPP, OVP, OCP, SCP, OTP, UVP, SIP, and NLO • ATX12V V2.52 power supply suitable for mainstream gaming and office PC builds Key Specifications Model: PF500X / PF600X / PF700X Product Type: ATX Power Supply Power: 500W / 600W / 700W Type: ATX12V V2.52 Efficiency Certification: 80PLUS 230 EU Bronze / CYBENETICS Bronze / CYBENETICS A 230V / PPLP 230V Bronze Efficiency: ≥88% Under Typical Load (50% Loading) Fan Size: 120mm Fan Bearing: Longlife HYB Topology: Active PFC + DC-to-DC Capacitors: Taiwanese + Japanese Electrolytic Capacitors Power Good Signal: 100–150ms Hold Up Time: ≥16ms (75% Load) Protection: OPP / OVP / OCP / SCP / OTP / UVP / SIP / NLO Operation Temperature: 0–40°C Regulatory: CE / TUV-RH / CCC / RCM / KC ErP Regulation: ErP 2014 MTBF: 40,000 Hours Dimensions: 150 × 140 × 86mm (W × L × H) Warranty: 3 Years Warranty
