Product

ASUS PRIME H610M-F WIFI D4 Micro ATX (mATX) Intel Motherboard | Intel LGA1700 Socket

Product Highlights • Supports Intel® Core™ 14th, 13th and 12th Gen processors • Intel® H610 chipset with LGA1700 socket • 2 x DDR4 DIMM slots supporting up to 64GB memory • Built-in Wi-Fi 6 and Bluetooth® 5.3 wireless connectivity • Realtek 1Gb Ethernet for stable wired networking • 1 x M.2 slot and 2 x SATA 6Gb/s ports for storage expansion • Micro ATX form factor suitable for compact PC builds Key Specifications Model: PRIME H610M-F WIFI D4 Product Type: Intel Motherboard Form Factor: Micro ATX / mATX Chipset: Intel H610 Socket: Intel LGA1700 CPU Support: • Intel® Core™ 14th Gen Processors • Intel® Core™ 13th Gen Processors • Intel® Core™ 12th Gen Processors • Intel® Pentium® Gold Processors • Intel® Celeron® Processors Memory: 2 x DDR4 DIMM Maximum Memory: Up to 64GB Memory Speed: DDR4 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 Memory Support: Dual Channel, Intel® XMP Video Output: • 2 x HDMI™ ports Expansion Slots: • 1 x PCIe 4.0 x16 slot • 1 x PCIe 3.0 x1 slot Storage: • 1 x M.2 slot, Key M, Type 2242 / 2260 / 2280 • Supports PCIe 3.0 x4 mode • 2 x SATA 6Gb/s ports Wireless Connectivity: Wi-Fi 6, Bluetooth® 5.3 LAN: Realtek 1Gb Ethernet Audio: Realtek 7.1 Surround Sound High Definition Audio CODEC Rear I/O Ports: • 2 x USB 5Gbps Type-A ports • 3 x USB 2.0 Type-A ports • 2 x HDMI™ ports • 1 x Wi-Fi module • 1 x Realtek 1Gb Ethernet port • 3 x Audio jacks Dimensions & Weight Dimensions: 22.6 x 18.8 x 2.0 cm Weight: 0.80 kg Warranty: 3 Years Warranty
